BCS BCS-AT3 PoE adaptér 24W 48V 0,5A 2-port 10/100 Mbps čierny

The BCS BCS-AT3 is a high-performance Power over Ethernet (PoE) adapter designed to deliver reliable power and data transmission for network devices. Compliant with IEEE 802.3af standard, it provides up to 24W of power over a single Ethernet cable, simplifying installation and reducing cable clutter. Ideal for IP cameras, VoIP phones, and wireless access points, this adapter ensures stable connectivity and efficient power management.

Advantages

Simplifies network setup by combining power and data over one cable, eliminating the need for separate power outlets near devices. Compact desktop design saves space and supports flexible placement. Built-in protection against overload and short circuits ensures safe operation and extends equipment lifespan.

Suitable for

• IP cameras and surveillance systems
• VoIP phones and communication devices
• Wireless access points and routers
• Any IEEE 802.3af compliant PoE device

Key specifications

• PoE Standard: IEEE 802.3af
• Output Power: 24 W
• Output Voltage: 48 V DC
• Output Current: 0.5 A
• Input Voltage: 100-240 V AC
• Input Frequency: 50/60 Hz
• Data Transfer Rate: 10/100 Mbps
• Ethernet Ports: 2 (1x Data In, 1x Data+Power Out)
• Connector Type: RJ45
• AC Power Connector: IEC C6 (Cloverleaf)
• LED Indicators: Power
• Protection: Overload, Short Circuit
• Operating Temperature: -10°C to 50°C
• Housing Material: Plastic
• Color: Black
• Mounting Type: Desktop

Recommendations

For optimal performance, use with IEEE 802.3af compliant devices. Ensure proper ventilation and avoid exposure to extreme temperatures or moisture. This adapter is not a switch; it injects power into the Ethernet cable for a single PoE device.
