CATA E-100 GS axiálny odťahový ventilátor 100 mm biely

Axial extractor fan engineered for continuous moisture control in bathrooms and utility rooms, delivering a powerful airflow of 98 m³/h through a 100 mm duct. The CATA E-100 GS combines high extraction efficiency with quiet operation at just 38 dB(A), ensuring a comfortable environment without disruptive noise.

Advantages

The fan features a backdraft shutter that automatically closes when not in use, preventing cold air and odours from entering through the duct. Its IPX4 rating protects against water splashes, making it safe for installation in humid zones. The long-life ball bearings extend the motor's lifespan, while the high-quality ABS plastic housing resists yellowing and impact, maintaining a clean white appearance over time.

Suitable for

• Bathrooms and shower rooms
• Toilets and cloakrooms
• Utility rooms and small kitchens
• Wall or ceiling mounting

Key specifications

• Duct diameter: 100 mm
• Airflow rate: 98 m³/h
• Noise level: 38 dB(A)
• Power consumption: 15 W
• Voltage: 230 V / 50 Hz
• IP rating: IPX4 (splash-proof)
• Material: High-quality ABS plastic
• Colour: White
• Bearing type: Long-life ball bearings
• Backdraft shutter included
• Motor speed: 2500 RPM
• Insulation class: Class II
• Certifications: CE, TÜV Rheinland

Recommendations

For optimal performance, install the fan as high as possible on the wall or ceiling, away from the door to maximise airflow across the room. Ensure the duct run is as short and straight as possible to maintain the specified extraction rate. The fan is designed for standard switched live control; for automatic operation, pair it with a separate humidistat or timer module (not included).
