Desktop DDR5-UDIMM-ECC-RAM modul HP 16 GB 5600 MT/s (1x16 GB)

HP 16GB DDR5 UDIMM ECC RAM module delivers a single 16GB unbuffered memory stick operating at 5600 MT/s, designed for desktop and workstation systems that support DDR5 UDIMM with ECC. The module provides error-correcting capability to detect and correct single-bit memory errors, improving data integrity and system stability in professional and multitasking environments. Manufactured to HP specifications and intended for systems that explicitly list support for DDR5 UDIMM ECC memory.

Advantages

The DDR5 UDIMM ECC design combines higher transfer rates with on-module error correction to reduce the likelihood of data corruption during operation. Operating at 5600 MT/s, this 16GB module increases available memory bandwidth for demanding applications while remaining compatible with platforms that require unbuffered ECC memory. Its single-stick form factor allows incremental upgrades and straightforward installation without the need for registered or buffered modules.

Suitable for

• Workstations running professional applications (CAD, content creation, data analysis)
• Desktop systems configured for ECC support and enhanced stability
• Virtualization hosts and light server tasks requiring memory error correction
• System upgrades where a single 16GB DDR5 UDIMM ECC module is needed

Key specifications

• Form factor: UDIMM (unbuffered DIMM) for desktop/workstation use
• Capacity: 16 GB single module
• Memory generation: DDR5
• Speed: 5600 MT/s data rate
• Error correction: ECC (single-bit error detection and correction)
• Voltage and timing: platform dependent; follow motherboard specifications
• Physical compatibility: standard DDR5 DIMM pinout for supported motherboards

How to use

Before installation, verify that the target motherboard or system firmware explicitly supports DDR5 UDIMM ECC modules. Power down the system, disconnect power, and discharge static electricity. Remove existing memory if necessary and align the module with the DIMM slot notch; press evenly until the retention clips engage. After installation, power on and check system firmware or OS memory reporting to confirm the full 16GB is recognized and ECC functionality is enabled if supported. When mixing modules, use identical or motherboard-recommended configurations to avoid compatibility issues.

Recommendations

Use this HP DDR5 UDIMM ECC module in systems that document support for unbuffered ECC DDR5 memory. For best results, update motherboard BIOS/UEFI to the latest recommended version and pair modules according to the motherboard manual. Avoid mixing ECC and non-ECC modules in the same system unless the platform explicitly allows it. Handle the module by its edges and store in anti-static packaging until installation.
