Nosná zostava 2,5-palcového pevného disku pre server Dell, model W125721012

2.5" Hard Drive Carrier Assembly for Dell servers, model W125721012 is a metal and plastic mounting frame designed to hold a 2.5-inch HDD or SSD securely in a compatible Dell server or workstation bay. The carrier aligns the drive with the system connector and bay latch, enabling tool-free insertion and removal in systems that accept this style of carrier. The assembly preserves drive orientation and electrical contact without modifying the drive itself, making it suitable for maintenance, replacements and capacity upgrades.

Advantages

This carrier assembly provides a precise mechanical fit and connector alignment for 2.5-inch drives, reducing installation time and minimizing risk of improper connection. The design supports hot-swap bays where applicable and protects the drive from excessive movement or shocks inside the chassis. Compatibility with Dell server drive bays maintains proper airflow and rack compatibility, while the carrier frame eliminates the need for custom brackets or adapters.

Suitable for

• Replacing a failed 2.5" HDD or SSD in a Dell server or workstation
• Upgrading storage capacity with a new 2.5" drive
• Servicing, testing or swapping drives during maintenance windows
• Enabling correct mechanical and connector fit in Dell drive bays

Key specifications

• Drive form factor: 2.5-inch HDD or SSD
• Material: metal frame with plastic retention elements
• Mounting style: bay carrier compatible with Dell server drive bays
• Connection alignment: aligns drive SATA/SAS connector to bay connector
• Cooling compatibility: maintains drive position for system airflow
• Installation type: front-access insertion and removal (where supported by chassis)

How to use

Insert the 2.5" drive into the carrier assembly, aligning the drive mounting holes with the carrier screw points and securing it with the appropriate screws if required by the carrier design. Slide the assembled carrier into the server bay until the latch engages and the drive connector mates with the bay connector. For replacement, unlock or release the bay latch according to the server documentation, pull the carrier out, remove the drive and install the replacement following the same steps. Verify the system recognizes the drive after installation and follow any server-specific procedures for hot-swap operations if supported.

Recommendations

Use compatible screw sizes and avoid overtightening to prevent drive or carrier damage. Confirm chassis and backplane compatibility before installation. Handle the drive and carrier on a static-free surface and follow the server manufacturer's maintenance instructions when performing hot-swap or replacement operations.
