HPE ProLiant DL20 GEN11 server Intel Xeon E-2436 2,9 GHz 16 GB DDR5

Description: HPE ProLiant DL20 Gen11 E-2436 2.9GHz 4-core 1P 16GB-U 4SFF Server The HPE P65396-421 is a single-processor rack server from the HPE ProLiant DL20 Gen11 family. It is designed for small and medium-sized businesses that need a compact and versatile device to handle a variety of workloads. Here are the key features of the server: Model: HPE ProLiant DL20 Gen11 Part number: P65396-421 Form: Rack-mounted Processor: Intel Xeon-E 2436 (6-Core 2.90GHz 18MB) RAM: 16 GB DDR5 4400B-E UDIMM (one 16 GB module) Storage: 4 Small Form-Factor (SFF) hard drive bays (HDD or SSD) Power supply: 800W Additional information: Scalability: The server supports memory expansion up to 128 GB and supports a variety of storage configurations with different drive capacities and interfaces. Management: HPE Integrated Lights Out (iLO) provides remote management capabilities for monitoring and configuring the server. Applications: This server is suitable for a variety of tasks, such as file and printer sharing, web hosting, point-of-sale (POS) systems, and remote office deployments. Things to note: Operating system: The HPE P65396-421 is sold without an operating system. You will need to purchase and install the operating system separately. Storage: The server does not come with any pre-installed drives. You will need to purchase compatible hard disk drives (HDDs) or solid-state drives (SSDs) depending on your specific needs. In summary, the HPE P65396-421 is a good choice for small and medium-sized businesses looking for an entry-level rack server that offers a balance of performance, versatility, and a compact size. | Model: HPE ProLiant DL20 Gen11 | Chipset type: Intel C262 | Number of CPUs installed: 1 | Max supported number of processors: 1 | CPU series: Intel Xeon (Hexa Core) | CPU model: E-2436 | CPU frequency: 2.9 | Number of cores: 6C | CPU - other information: Intel Xeon E-2436 (6-Core, 2.9 GHz, 65W) | RAM memory installed: 16 | Max memory size: 128 | Memory type: DDR5 | Kind of memory: ECC | Kind of memory: Unbuffered | Memory frequency: 4800 MHz | Number of memory slots used: 1 | Number of available memory slots: 3 | Total number of memory slots: 4 | RAM - other information: 16 GB UDIMM DDR5 4800 MT/s (1x16 GB) Notes: Runs at 4400 MT/s per processor support System maximum memory capacity - up to 64GB via field upgrade (4x16GB) | Network interface: 4 x 10/100/1000 Mbit/s | Disk controller: SATA | RAID levels: 10 (1+0) | RAID levels: 0 | RAID levels: 1 | RAID levels: 5 | Controller - other information: Embedded Intel VROC SATA software RAID Notes: SATA only | Form factor (width): 2,5'' (SFF) | Hot-swapping support: Yes | Hard drive cage interfaces: SAS | Hard drive cage interfaces: SATA | Max. number of disks in current configuration: 4 | Number of HDDs installed: 0 | Optical disk drive: None | Internal backup device support: No | Expansion slots: 1 x PCIe 5.0 x 16 | I/O connectors: 4 x RJ-45 LAN | I/O connectors: 7 x USB 3.0 | I/O connectors: 1 x USB Service | I/O connectors: 1 x 15-pin D-Sub | I/O connectors: 1 x DisplayPort | Number of power supplies installed: 1 | Max. number of power supplies: 2 | Power supply output current: 800 | PSU efficiency: 96 | Hot-plug power supply support: Yes | Number of fans: 3 | Hot-plug fans support: No | Housing: Rack 1U | Height: 4.32 | Width: 43.46 | Depth: 37.84 | Weight: 12 | Tower to rack conversion support: No | Warranty: Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response | Accessories included: HPE Short Friction Rail Kit | Color: Not applicable | Other features: PCI-Express Slots: 1 PCIe 5.0 CEM slot, 1 Internal OCP Storage Controller slot, 1 External OCP 3.0 Network Controller slot

How to use

Install the server into a standard 19" rack using appropriate rails and mount hardware. Populate memory modules in matched pairs according to the server memory population rules to reach required capacity up to 128 GB across four DIMM slots. Install one or two 3.5" SATA drives in the drive bays and configure RAID if redundancy or performance improvements are desired. Connect power and network cabling, then proceed with operating system installation and HPE management agent setup to enable firmware updates and hardware monitoring.

Recommendations

For reliable operation, use enterprise-class SATA drives and populate memory using HPE-qualified DIMMs. Configure hardware RAID for production workloads and enable power supply redundancy in environments where uninterrupted availability is required. Regularly update firmware and drivers through HPE management tools to maintain stability and security.
