LENOVO THINKPAD FIBOCOM L860-GL-16 4G LTE CAT16 M.2 WWAN MODUL PRE T14/P14S GEN 4

For professionals who demand uninterrupted connectivity beyond Wi-Fi, the Lenovo ThinkPad Fibocom L860-GL-16 module delivers integrated 4G LTE with Cat16 speeds directly to your compatible ThinkPad. This M.2 3042 card is engineered specifically for the ThinkPad T14 Gen 4 and P14s Gen 4, ensuring a seamless fit and reliable performance. Unlike external dongles, it occupies the internal WWAN slot, keeping your workspace clean while providing always-on access to cellular networks.

Highlights

• Fibocom L860-GL-16 module with 4G LTE Cat16 technology
• Theoretical download speeds up to 1 Gbps and upload up to 150 Mbps
• M.2 3042 form factor with PCIe Gen2 interface
• Supports 4x4 MIMO and up to 5x carrier aggregation
• Integrated GNSS: GPS, GLONASS, BeiDou, Galileo
• eSIM support for flexible carrier activation
• 2x MHF4 antenna connectors and Nano-SIM slot
• Compatible with Lenovo ThinkPad T14 Gen 4 and P14s Gen 4

In daily use

Stay productive on the go with secure, high-speed cellular connectivity. The L860-GL-16 module allows you to connect to LTE networks across a wide range of bands, making it suitable for international travel. With carrier aggregation and 4x4 MIMO, you can enjoy faster data rates and improved signal reliability in challenging environments. The module supports eSIM, enabling easy provisioning without physical SIM cards. Whether you're in a remote office or commuting, this module keeps you connected to critical business applications.

Full specifications

• Wireless Technology: 4G LTE
• LTE Category: CAT16
• Form Factor: M.2 3042
• Interface: PCIe Gen2
• Module Manufacturer: Fibocom
• Max Download Speed: Up to 1 Gbps (theoretical)
• Max Upload Speed: Up to 150 Mbps (theoretical)
• Carrier Aggregation: Supported (up to 5x CA)
• MIMO Support: 4x4 MIMO
• GNSS Support: GPS, GLONASS, BeiDou, Galileo
• Antenna Connectors: 2x MHF4
• SIM Card Type: Nano-SIM (4FF)
• Supported Bands (LTE FDD): B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B21, B25, B26, B28, B29, B30, B32, B66, B71
• Supported Bands (LTE TDD): B38, B39, B40, B41, B42, B43, B46, B48
• Compatibility: Lenovo ThinkPad T14 Gen 4, Lenovo ThinkPad P14s Gen 4
• Operating System Support: Windows 10/11, Linux
• Power Supply: 3.3V
• Operating Temperature: -10°C to +55°C
• Certifications: CE, FCC, GCF, PTCRB, RoHS
• Additional Features: eSIM support

Final note

Engineered for the modern mobile professional, this Lenovo WWAN module provides the freedom to work from anywhere with confidence.
