Napájací zdroj MEAN WELL SCW20A-12, 20 W výstupný výkon, 12 V

MEAN WELL SCW20A-12 is a compact DC-DC converter designed for PCB mounting that delivers a regulated 12 Vdc output at up to 1.67 A from a 9–18 Vdc input range. Housed in a DIP through-hole package, this 20 W power adapter/inverter is intended for low-power electronic equipment where a stable DC supply is required. The unit meets RoHS requirements and is offered in bulk quantities for manufacturing and installation projects.

Advantages

The converter provides a stable 12 V output with up to 20 W of power in a small DIP through-hole form factor suitable for PCB integration. Its wide 9–18 V input range supports varied source voltages, and the regulated output reduces the need for additional circuitry. The compact size and through-hole mounting make it straightforward to install in custom boards and prototypes. RoHS compliance ensures it meets common environmental and regulatory requirements for electronic assemblies.

Suitable for

• LED modules and small lighting systems
• Embedded control units and single-board controllers
• Communication devices and modems with 12 V supply requirements
• Industrial sensors and monitoring modules
• Small battery-powered systems requiring voltage conversion

Key specifications

• Output power: 20 W
• Output voltage: 12 Vdc
• Maximum output current: 1.67 A
• Input voltage range: 9–18 Vdc
• Mounting style: DIP through-hole for PCB mounting
• Package type: Through-hole converter suitable for soldering to PCB
• Regulation: Regulated DC output for stable voltage supply
• Compliance: RoHS

How to use
