CAIMAN 600 Zváračský batoh – 600A benzínový zváračský generátor s motorom Honda GX390

Delivering a massive 600A DC welding output with a 35% duty cycle at full power, the CAIMAN 600 Welding Rucksack is built for the toughest stick welding jobs in the field. Powered by a reliable Honda GX390 petrol engine, this machine provides both welding current and auxiliary power, making it a complete mobile workhorse.

Overview

The CAIMAN 600 is a professional engine-driven welder generator designed for MMA (stick) welding. Its rugged construction and IP23 protection allow operation in harsh environments. The unit provides 600A maximum welding current, suitable for electrodes up to 8mm, and offers auxiliary power outputs of 5 kVA single-phase and 10 kVA three-phase for running tools and lights.

What stands out

• High output: 40-600A DC welding range with 35% duty cycle at 600A, 60% at 500A, and 100% at 400A.
• Reliable power: Honda GX390 13 HP petrol engine with electric start and 25L fuel tank for extended operation.
• Dual auxiliary power: 230V single-phase (5 kVA) and 400V three-phase (10 kVA) outlets for job site versatility.
• Advanced welding features: Arc Force, Hot Start, Anti-Stick, and VRD (Voltage Reduction Device) for safety and performance.
• Portable design: Integrated rucksack-style frame for easy transport to remote locations.

Technical details

• Welding process: MMA (Stick)
• Engine: Honda GX390, 4-stroke petrol, 13 HP / 9.6 kW
• Welding current range: 40 - 600 A DC
• Duty cycle: 35% @ 600A, 60% @ 500A, 100% @ 400A
• Auxiliary power: 230V / 50Hz / 5 kVA (single-phase), 400V / 50Hz / 10 kVA (three-phase)
• Fuel tank capacity: 25 Liters
• Fuel type: Unleaded Petrol
• Starting system: Electric Start
• Max electrode diameter: 8 mm
• Protection class: IP23
• Noise level (7m): 97 dB(A)

Our verdict

The CAIMAN 600 Welding Rucksack combines exceptional welding power, reliable Honda engine performance, and versatile auxiliary outputs in a portable package, making it the ultimate choice for demanding field welding applications.
