RUKO FRS-DIN8033-HM-TiAlN-Ø10,0mm VHM stopková fréza

The RUKO FRS-DIN8033-HM-TiAlN-Ø10,0mm is a solid carbide end mill engineered for precision milling in demanding materials. Its TiAlN coating provides high hardness and heat resistance, enabling higher cutting speeds and longer tool life compared to uncoated end mills. The 4-flute design with 30° helix angle ensures smooth cutting action and efficient chip evacuation, making it suitable for both roughing and finishing operations.

Highlights

• Solid carbide construction for high rigidity and wear resistance
• TiAlN coating for superior hardness and thermal stability
• 4 flutes with 30° helix angle for excellent chip removal
• Center cutting capability allows plunge milling
• Precision ground to DIN 8033 standard with h6 shank tolerance

In daily use

This end mill excels in universal milling applications across a wide range of materials, including steel, stainless steel, cast iron, non-ferrous metals, and high-temperature alloys. Its square end geometry produces sharp 90° corners, ideal for slotting, profiling, and pocketing. The right-hand cut direction is compatible with standard spindle rotations, and the tool can be used with external cooling or dry machining.

Full specifications

• Tool type: End Mill
• Standard: DIN 8033
• Material: Solid Carbide (VHM)
• Coating: TiAlN (Titanium Aluminum Nitride)
• Cutting diameter (D1): 10.0 mm
• Shank diameter (D2): 10.0 mm
• Overall length (L1): 72 mm
• Cutting length (L2): 22 mm
• Number of flutes: 4
• Helix angle: 30°
• Cutting edge type: Square End
• Center cutting: Yes
• Shank tolerance: h6
• Direction of cut: Right-hand
• Manufacturing process: Precision Ground
• Recommended cooling: External or Dry Machining

Final note

A professional-grade end mill that delivers consistent performance and dimensional accuracy for high-precision milling tasks.
