RUKO FRS-DIN8033-HM-TiAlN-Ø12,0mm VHM stopková fréza

Solid carbide end mill with TiAlN coating, 12.0 mm cutting diameter, 4 flutes, right-hand cut, for milling steel, stainless steel, cast iron, non-ferrous metals and high-temperature alloys.

Advantages

TiAlN coating provides high hardness and heat resistance, allowing higher cutting speeds and longer tool life. Solid carbide construction ensures rigidity and precision. Suitable for both roughing and finishing operations.

Suitable for

• General purpose milling in steel and stainless steel
• Cast iron and non-ferrous metals
• High-temperature alloys
• Wet or dry machining

Key specifications

• Cutting diameter (d1): 12.0 mm
• Shank diameter (d2): 12.0 mm
• Overall length (l1): 83 mm
• Flute length (l2): 26 mm
• Number of flutes: 4
• Helix angle: 30°
• Shank type: cylindrical, tolerance h6
• Cutting diameter tolerance: h10
• Edge geometry: sharp edge
• Coating: TiAlN
• Material: solid carbide (VHM)
• Standard: DIN 8033

Recommendations

For optimal performance, use appropriate cutting parameters for the workpiece material and machine rigidity. Suitable for CNC milling machines and machining centers.
