RUKO FRS-DIN8033-HM-TiAlN-Ø12,0mm VHM stopková fréza

Solid carbide end mill with TiAlN coating for general-purpose milling in steel, stainless steel, cast iron, and non-ferrous metals. Precision ground with 4 flutes and 30° helix angle for efficient chip evacuation.

Advantages

TiAlN coating provides high wear resistance and allows higher cutting speeds. Solid carbide construction ensures rigidity and precision. Center cutting design enables plunge milling.

Suitable for

• Steel
• Stainless steel
• Cast iron
• Non-ferrous metals

Key specifications

• Cutting diameter: 12.0 mm
• Shank diameter: 12.0 mm
• Overall length: 75 mm
• Cutting length: 26 mm
• Number of flutes: 4
• Helix angle: 30°
• Shank tolerance: h6
• Standard: DIN 8033

Recommendations

Use with external coolant for best results. Suitable for a wide range of milling operations in general engineering.
