RUKO MGR-DIN357-M20x2.5mm montážny adaptér na DIN lištu

DIN rail mounting adapter for Pflitsch MGR-System, enabling snap-on installation of cable glands with M20 x 2.5 mm thread onto standard TS 35 rails. Constructed from light grey polyamide PA 6, it provides a secure and durable mounting solution for industrial enclosures and machinery.

Advantages

Tool-free snap-on mounting to DIN rail TS 35 (EN 60715) saves installation time. The adapter's polyamide PA 6 body offers high mechanical strength and resistance to oils and greases. Its light grey colour (RAL 7035) blends seamlessly into control cabinet environments.

Suitable for

• Industrial control cabinets and enclosures
• Machinery requiring cable gland mounting on DIN rails
• Use with Pflitsch MGR-System cable glands with M20 x 2.5 mm thread

Key specifications

• Product Type: DIN Rail Mounting Adapter
• System: Pflitsch MGR-System
• Mounting Standard: DIN Rail TS 35 (EN 60715)
• Compatible Cable Gland Thread: M20 x 2.5 mm
• Material: Polyamide PA 6
• Colour: Light Grey (RAL 7035)
• Temperature Range (Static): -40°C to +100°C
• Temperature Range (Dynamic): -20°C to +80°C
• Flammability Rating: UL94 V-2
• Number of Cable Entries: 1 (via compatible gland)
• Thread Type: Metric
• Thread Pitch: 2.5 mm
• Installation: Snap-on to DIN rail

Recommendations

Pair with Pflitsch MGR-System cable glands with M20 x 2.5 mm thread for a complete, secure cable entry solution on DIN rails.
