Victron Energy Orion-Tr DC-DC menič 24/12-9A 110W izolovaný

The Victron Energy Orion-Tr DC-DC Converter 24/12-9A 110W is a high-efficiency, isolated DC-DC converter designed to convert a 24V DC input to a stable 12.2V DC output. Ideal for automotive, marine, and off-grid applications, this converter ensures reliable power conversion with galvanic isolation.

Advantages

Galvanic isolation protects sensitive equipment from voltage spikes and ground loops. The fanless convection cooling ensures silent operation and long lifespan. With an efficiency of 87%, it minimizes power loss. The remote on/off feature allows easy control.

Suitable for

• Charging 12V batteries from a 24V vehicle system
• Powering 12V appliances in trucks, boats, and RVs
• Off-grid solar systems with 24V battery banks

Key specifications

• Input voltage range: 18-35V DC
• Output voltage: 12.2V DC (adjustable 10-15V)
• Output current: 9A
• Continuous output power: 110W
• Efficiency: 87%
• No-load current: <80mA
• Operating temperature: -20 to +55°C
• Protection: Output short circuit, over temperature
• Enclosure: IP43 (screw terminals downwards)
• Connection: Screw terminals
• Mounting: Surface mount

Recommendations

For optimal performance, ensure proper ventilation and mount with screw terminals facing downwards to maintain IP43 rating. Use appropriate wire gauges for the 9A output.
