AG Neovo 55-palcový 1080p 500 Nits ultra tenký rám video-wall displej

The PN-55D3 55-Inch 1080p 500 nits ultra-narrow bezel displays are designed for commercial and professional large-scale video wall installations. Given its built-in scheduler, OPS slot, UniWall™ feature, the PN-55D3 high-end video wall displays can easily create 15×15 large-scale and eye-catching digital content without third-party devices. The anti-reflective, 500 nits brightness panel makes visually stunning video walls in demanding environments — from large public venues to 24/7 operation control rooms.

IMMERSIVE VISUAL EXPERIENCE

To ensure that viewers are presented with an uninterrupted visual experience, the PN-55D3 features IPS panel technology with 24/7 operation. The display is further enhanced by a minuscule 3.5 mm bezel-to-bezel transition to create immersive video walls.

ANTI-GLARE COATING WITH HIGH VISIBILITY

Anti-glare treatment with the haze of 28%, high contrast, wide viewing angles, and 500 nits brightness produce images with superior clarity and visibility under ambient light.

PATENTED ANTI-BURN-IN™ TECHNOLOGY

To combat the effects of traditional LCD burn-in or ghosting, AG Neovo utilises its patented Anti-Burn-in™ Technology to prevent image burn-in and ensure an extended lifespan for displays.

GAMMA SETTINGS FOR CORRECTING COLOUR TONES

The PN-55D3 video wall displays can provide real-time adjustment on the spot. Additionally, multiple sets of Gamma settings produce smoother and more consistent colour tones.

COLOUR CALIBRATION FOR VIDEO WALL SETUP

Screen colour varies due to temperature changes or after long-term use. Fortunately, AG Neovo offers a colour calibration tool, which detects each area using on-screen sensors and automatically fine-tunes colours and details for large-scale display installations.

* This requires consultation with an AG Neovo sales representative.

15x15 LARGE-SCALE VIDEO WALLS

The UniWall™ feature allows the PN-55D3 to natively support video walls of up to 15×15 displays, which can easily be connected to external sources.

DISPLAYPORT 1.2 MULTISTREAM AND IR/RS232 CONTROL CAPABILITY

The DisplayPort 1.2 Multistream functionality allows users to set up, configure, and maintain a 2×2 4K video wall with ease. Users can also easily control multiple PN-55D3 displays via IR or RS232 connections to external devices.

POWERFUL OPS SLOT-IN OPTION

The embedded OPS slot is ready for standardised OPS module installation. Accordingly, the PN-55D3 video wall displays can be seamlessly upgraded to powerful digital signage that is tailor-made for various user scenarios.

LANDSCAPE/PORTRAIT CAPABILITY

The PN-55D3 video wall displays are signage-friendly and can perfectly fit in landscape or portrait mode for complete screen orientation flexibility and to fulfil the needs of various scenarios.

PID COMMAND & CTRL SOFTWARE

PID Command & Ctrl provides intuitive user interfaces for remote management via laptops and mobile devices and offers the easy creation of video wall displays. The software also features simple colour calibration, temperature checks, IR/key-locking options, and usage monitoring for daily maintenance.

AG Neovo 55-Inch 1080p 500 Nits Ultra Narrow Bezel Video Wall Display. Product design: Digital signage flat panel. Display diagonal: 138.7 cm (54.6"), Display technology: LCD, Display resolution: 1920 x 1080 pixels, Display brightness: 500 cd/m², HD type: Full HD. Operating hours (hours/days): 24/7. Product colour: Black

How to use

Install the PN-55D3 using the appropriate VESA mount or frame for video wall configurations and connect source devices via HDMI, DisplayPort (supporting DP 1.2 Multi-Stream), or an OPS module installed in the OPS slot. Configure orientation in landscape or portrait mode depending on the installation needs. Use the UniWall™ feature to assemble and manage multi-panel layouts up to 15×15 and employ PID Command & Ctrl software to perform remote configuration, scheduling, and routine maintenance. For best uniformity across panels, perform on-screen colour calibration using the AG Neovo tool in coordination with a sales representative.

Recommendations

For long-term installations and optimal uniformity in large video walls, schedule periodic colour calibration and use PID Command & Ctrl for centralized monitoring. Consult an AG Neovo sales representative when planning 15×15 or custom large-scale deployments to ensure correct calibration and connectivity.
