ALLNET ALL-SMC6622SCHWARZ 19" 2U racková skriňa pre mediálne konvertory, 16 slotov, čierna

Where most rackmount chassis simply house modules, the ALLNET ALL-SMC6622SCHWARZ actively protects your network uptime with redundant hot-swappable power supplies and dual cooling fans. This 19-inch 2U enclosure consolidates up to 16 ALLNET ALL-SMC6622 series media converters into a single, manageable unit—ideal for data centers and enterprise wiring closets that demand centralized fiber-to-copper conversion without sacrificing reliability.

Highlights

• 16 module slots for ALLNET ALL-SMC6622 series media converters
• Redundant internal power supplies (2x hot-swappable) with 100–240V AC input and 5V DC / 16A output
• Active cooling via two hot-swappable fans
• LED indicators for power, fan status, and per-slot module status
• Robust black metal construction, 19-inch rackmount, 2U height

In daily use

Install the chassis in a standard 19-inch rack, slide in your media converters, and connect the AC power cords. The redundant PSUs ensure that if one supply fails, the other takes over without interrupting network traffic. Hot-swappable fans allow replacement while the system remains online, and the per-slot LEDs let you identify a faulty module at a glance. The chassis operates reliably in temperatures from 0°C to 50°C and relative humidity from 10% to 90% (non-condensing), making it suitable for a range of server room environments.

Full specifications

• Rack size: 19 inch
• Rack units: 2U
• Colour: Black
• Material: Metal
• Number of slots: 16
• Compatible products: ALLNET ALL-SMC6622 series media converters
• Power supply type: Internal, redundant
• Number of power supplies: 2 (hot-swappable)
• AC input voltage: 100–240 V
• AC input frequency: 50/60 Hz
• Output voltage: 5 V DC
• Output current: 16 A max
• Cooling: Active, 2 hot-swappable fans
• LED indicators: Power, fan status, module status (per slot)
• Operating temperature: 0–50 °C
• Operating relative humidity: 10–90% (non-condensing)
• Mounting type: Rackmount

Final note

For network architects who refuse to compromise on uptime or scalability, this chassis delivers a centralized, serviceable platform that keeps your media conversion layer running smoothly.
