BALS 71099 QUICK-CONNECT Nástenná zásuvka Schuko 16A 250V IP44 sivá

Electricians and maintenance teams working in damp or dusty environments—such as workshops, garages, basements, and outdoor covered areas—need a reliable power connection that withstands splashes and mechanical stress. The BALS 71099 surface-mounted Schuko socket outlet answers that call with its robust IP44-rated housing and tool-free QUICK-CONNECT terminals, ensuring fast installation and long-term safety.

Key specifications

• Socket standard: Schutzkontakt (Schuko) with earth contact
• Rated current: 16 A; rated voltage: 250 V AC; frequency: 50/60 Hz
• Protection class: IP44 (splash-proof)
• Mounting type: surface-mounted, rear cable entry
• Connection technology: QUICK-CONNECT screwless push-in terminals
• Number of conductors: 2P+E (phase, neutral, earth)
• Max. conductor cross-section: 2.5 mm²
• Housing material: polyamide (PA6), colour grey (RAL 7035)
• Hinged lid for protection when not in use
• Operating temperature: -25 °C to +40 °C
• Glow wire test: 850 °C; flammability rating: UL94 V-2
• Standards compliance: DIN VDE 0620-1, IEC 60884-1

Why choose it

The QUICK-CONNECT terminals eliminate the need for screwdrivers—simply strip the wire and push it in for a secure, vibration-resistant connection. The IP44 rating means the socket is protected against water splashes from any direction, making it suitable for areas where moisture is a concern. The robust polyamide housing resists impact and chemicals, ensuring durability in industrial settings. The hinged lid keeps the contacts clean and safe when the socket is not in use.

Ideal use cases

• Workshops and garages where power tools require frequent plugging/unplugging
• Basements, laundry rooms, and other damp indoor areas
• Covered outdoor spaces such as carports or terraces
• Industrial environments needing reliable, splash-proof power outlets

Good to know

The socket is designed for fixed installation with rear cable entry. It complies with German and international standards, ensuring compatibility with standard Schuko plugs. For optimal performance, use conductors up to 2.5 mm². The grey RAL 7035 colour blends discreetly into most industrial and commercial settings.
