BCS BCS-EA55VSR4(H2) 5MP HD analógová bullet kamera s 2,8mm objektívom, 4-in-1 AHD/TVI/CVI/CVBS, 20m IR, IP66

Poor image quality and limited compatibility can cripple a surveillance system. The BCS BCS-EA55VSR4(H2) solves this with a 5-megapixel CMOS sensor and 4-in-1 video output (AHD/TVI/CVI/CVBS), ensuring crisp, detailed footage and seamless integration with existing DVRs. Its 2.8mm fixed lens delivers a wide 100° field of view, while Smart IR illumination reaches up to 20 meters in total darkness. Housed in a weatherproof IP66-rated enclosure, this bullet camera is built for reliable outdoor performance.

Who is it for

This camera is ideal for home and business owners who need a high-resolution, cost-effective surveillance solution that works with a variety of analog HD recorders. It's perfect for monitoring driveways, entrances, backyards, and small commercial areas, day or night.

Main features

• 5MP high-resolution sensor (2592x1944) for sharp, detailed images
• 4-in-1 video output: AHD, TVI, CVI, and CVBS for broad DVR compatibility
• 2.8mm fixed lens with approximately 100° horizontal field of view
• Smart IR night vision up to 20 meters with automatic exposure control
• IP66 weatherproof housing for outdoor use in harsh conditions
• Digital Wide Dynamic Range (DWDR) and 2D/3D noise reduction for clear images in challenging lighting
• On-screen display (OSD) menu controllable via coaxial cable (UTC)

Specifications

• Sensor: 1/2.7" CMOS, 5 megapixels
• Resolution: 2592 x 1944 (5MP)
• Frame rate: 5MP@20fps, 4MP@25/30fps, 2MP@25/30fps
• Lens: Fixed 2.8mm, horizontal angle approx. 100°
• Minimum illumination: 0.001 Lux (Color), 0 Lux (IR On)
• Digital Wide Dynamic Range (DWDR): Yes
• Digital Noise Reduction (DNR): 2D/3D DNR
• Backlight Compensation (BLC): Yes
• Highlight Compensation (HLC): Yes
• Automatic Gain Control (AGC): Yes
• On-Screen Display (OSD) Menu: Yes (Coax/UTC Control)
• Ingress Protection Rating: IP66
• Housing Material: Plastic
• Power Supply: DC 12V
• Power Consumption: Max 3W
• Operating Temperature: -30°C to +60°C

Tips

For optimal performance, mount the camera at a height of 2.5-3 meters and angle it slightly downward. Use a compatible HD DVR to take full advantage of the 5MP resolution. Clean the lens periodically to maintain image clarity.
