BCS BCS-V-KN videovrátnik vonkajšia stanica, 2MP, 2-drôt, strieborná/sivá

The BCS BCS-V-KN is a high-quality video door phone outdoor panel designed for modern access control and communication systems. Built with a durable aluminum alloy housing and rated IP65/IK07, it withstands harsh weather and vandalism. Featuring a 2MP CMOS camera with 2.8mm wide-angle lens, 120° horizontal and 69° vertical viewing angles, and IR night vision, it ensures clear video day and night. Two-way audio with built-in microphone and speaker enables seamless visitor communication. The panel connects via a 2-wire system and includes one call button and one relay output for door/gate control. Compatible with BCS Line 2-Wire systems, it operates on DC 24V from the system and functions in temperatures from -30°C to +60°C.

Advantages

Robust aluminum alloy construction with IP65/IK07 protection ensures long-lasting performance in outdoor environments. The 2MP camera with wide-angle lens and IR night vision delivers crisp images even in low light. Two-way audio allows clear conversation with visitors. Simple 2-wire connectivity integrates easily with existing BCS systems. One relay output provides reliable door/gate control.

Suitable for

• Residential buildings
• Office complexes
• Apartment blocks
• Small commercial properties

Key specifications

• Product Type: Video Door Phone Outdoor Panel
• Camera Sensor: 2MP CMOS
• Lens Type: 2.8mm Wide-Angle
• Horizontal Viewing Angle: 120°
• Vertical Viewing Angle: 69°
• Night Vision: IR Illumination
• Audio Communication: Two-way, Built-in Mic & Speaker
• Connectivity: 2-Wire System
• Material: Aluminum Alloy
• Mounting Type: Surface Mount
• Ingress Protection (IP) Rating: IP65
• Vandal Resistance (IK) Rating: IK07
• Operating Temperature: -30°C to +60°C
• Power Supply: DC 24V (from system)
• Number of Call Buttons: 1
• Door/Gate Control: 1 x Relay Output
• Compatibility: BCS Line 2-Wire Systems
• Color: Silver/Grey

Recommendations

For optimal performance, ensure compatibility with BCS Line 2-Wire indoor stations and power supply. Professional installation recommended.
