BCS-MON7400B-S 7" TFT-LCD monitor s HDMI, VGA, BNC, čierny

The BCS-MON7400B-S is a professional 7-inch TFT-LCD monitor designed for surveillance and industrial applications. With a native resolution of 800x480, it delivers clear and detailed images. The monitor features multiple video inputs including HDMI, VGA, and BNC, making it versatile for various setups. Built-in speakers and audio inputs/outputs provide complete multimedia functionality.

Advantages

Compact and lightweight design with VESA 75x75mm mounting compatibility for flexible installation. The 3D comb filter and 3D noise reduction enhance image quality, while PIP/PBP functions allow simultaneous viewing of multiple sources. Low power consumption under 8W makes it energy-efficient.

Suitable for

• Security and CCTV monitoring systems
• Industrial control and automation displays
• Portable video monitoring in broadcast or field applications
• Embedded systems requiring a small form factor display

Key specifications

• Display: 7-inch TFT-LCD, 800x480 resolution, 16:9 aspect ratio
• Brightness: 300 cd/m², Contrast Ratio: 500:1
• Viewing Angles: 140° horizontal / 120° vertical
• Video Inputs: 2x BNC (CVBS), 1x HDMI, 1x VGA
• Audio Inputs: 2x RCA (L/R), Audio Output: 1x RCA (L/R)
• Built-in Speakers: 2x 1W
• Power Supply: DC 12V / 1A, Power Consumption: < 8W
• Mounting: VESA 75x75mm, Desktop Stand included
• Housing: Plastic, Color: Black

Recommendations

For optimal performance, use a regulated 12V DC power supply. The monitor is ideal for environments where space is limited but reliable video monitoring is required.
