BCS PulsON LCD(BLU)/S WH 16x2 znakový LCD displej modul, modré podsvietenie, biely text, 5V

The BCS PulsON LCD(BLU)/S WH is a high-quality 16x2 character LCD display module featuring a blue backlight and white text for clear readability. Designed for easy integration into embedded systems, this module uses a standard HD44780-compatible controller and supports parallel interface (4-bit or 8-bit). It operates at 5V DC and is ideal for applications requiring alphanumeric output.

Advantages

This display offers excellent contrast and brightness, making it suitable for both indoor and outdoor use. The blue backlight enhances visibility in low-light conditions, while the white text ensures high legibility. With a wide operating temperature range and low power consumption, it is reliable for industrial and consumer electronics.

Suitable for

• Embedded systems and microcontroller projects
• Industrial control panels
• Point-of-sale terminals
• Medical devices
• Home automation displays

Key specifications

• Display Format: 16 Characters x 2 Lines
• Backlight Color: Blue
• Text Color: White
• Controller IC: HD44780 Compatible
• Interface: Parallel (4-bit/8-bit selectable)
• Supply Voltage: 5V DC
• Current Consumption (Backlight On): Approx. 20mA
• Viewing Angle: 6 o'clock
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -30°C to +80°C
• Module Dimensions (L x W x H): 80 x 36 x 13 mm
• Viewing Area (L x W): 64.5 x 16 mm
• Character Size (W x H): 2.95 x 5.55 mm
• Dot Size (W x H): 0.55 x 0.65 mm
• Pin Count: 16-pin
• Mounting Type: Through-hole pins
• Contrast Adjustment: External Potentiometer Required

Recommendations

For optimal performance, use an external potentiometer to adjust contrast. Ensure stable 5V DC power supply. This module is compatible with Arduino, Raspberry Pi, and other microcontrollers.
