Bopla BoPad BOP 10.1 P-9016-SET puzdro na displej 285 x 198 x 92,90 mm ABS biela RAL 9016 35110176.HMT1

The Bopla BoPad BOP 10.1 P-9016-SET stands out as a purpose-built display enclosure for 10.1-inch HMI panels, offering a clean white RAL 9016 finish and robust ABS construction. Unlike generic enclosures, it integrates a dedicated display mounting area and a two-part screw-fastened shell for straightforward assembly.

Highlights

• Designed for 10.1-inch displays and HMI applications
• Molded from durable ABS plastic in white (RAL 9016)
• External dimensions: 285 mm length, 198 mm width, 92.90 mm height
• Two-part shell with screw-fastened assembly
• Supplied as a single piece (P-SET configuration)

In daily use

This enclosure provides a stable, protective housing for embedded display systems in industrial or commercial settings. The integrated mounting area simplifies panel installation, while the robust ABS material withstands everyday handling. The white finish suits clean, modern equipment designs.

Full specifications

• Product type: Display enclosure
• Enclosure series: BoPad
• Material: ABS (Acrylonitrile Butadiene Styrene)
• Colour: White (RAL 9016)
• External length: 285 mm
• External width: 198 mm
• External height: 92.90 mm
• Application suitability: Human Machine Interface (HMI), display devices
• Construction: Two-part shell, screw-fastened
• Package quantity: 1 piece
• Model variant: P-SET

Final note

A reliable choice for integrating 10.1-inch displays into custom HMI systems, with a clean white aesthetic and straightforward assembly.
