Busch-Jaeger 6725 2-kanálový spínací/stmievací aktor, pod omietku, 230V, free@home

Managing lighting circuits in a modern smart home often means juggling multiple switches and dimmers, but the Busch-Jaeger 6725 actuator consolidates control into a single flush-mounted unit. This two-channel switching/dimming actuator integrates seamlessly with the Busch-Jaeger free@home system, enabling precise control of lighting loads directly from the bus. Whether you need to switch lights on and off or dim them to the perfect level, this actuator handles both functions with universal dimming capability for a wide range of lamp types.

Who is it for

Electricians, system integrators, and homeowners building or upgrading a free@home smart home installation. It is ideal for those who want a discreet, in-wall solution for controlling two independent lighting circuits without visible control modules.

Main features

• Two independent channels for switching or dimming lighting loads.
• Universal dimming principle supports leading-edge and trailing-edge dimming.
• Compatible with incandescent, halogen (HV and LV with electronic or conventional transformers), dimmable LED, and dimmable CFL lamps.
• Compact flush-mounted design fits standard wall boxes (dimensions: 47 mm width, 48 mm height, 14 mm depth).
• Connects to the free@home bus for centralized control and automation.
• Per-channel maximum load: 100 W/VA; minimum load: 10 W/VA.
• Protection class IP20, suitable for indoor use in dry environments.

Specifications

• Product type: Switching/dimming actuator
• Mounting type: Flush-mounted (Unterputz)
• Number of channels: 2
• Control system: Busch-Jaeger free@home
• Power source: AC
• Input voltage: 230 V AC
• Input frequency: 50 Hz
• Max. switching/dimming power per channel: 100 W/VA
• Minimum load per channel: 10 W/VA
• Dimming principle: Universal (leading/trailing edge)
• Supported load types: Incandescent, HV halogen, LV halogen (electronic/conventional), dimmable LED, CFL
• Protection class: IP20
• Operating temperature: 0 - 45 °C
• Communication protocol: free@home bus
• Dimensions (W x H x D): 47 x 48 x 14 mm

Tips

Ensure the connected load meets the minimum requirement of 10 W/VA per channel to avoid flickering or malfunction. For LED or CFL dimming, verify compatibility with the universal dimming principle. Always install by a qualified electrician and follow local wiring regulations.
