Dahua IP kamera IPC-HFW2441DG-4G-SP-B-0360B

The Dahua IPC-HFW2441DG-4G-SP-B-0360B is a wireless IP security camera with a 1/3" CMOS sensor and a maximum resolution of 2560 x 1440. It features a fixed 3.6 mm lens with an F1.6 aperture and offers IR illumination up to 30 m and warm light up to 20 m.

Key features

• 4MP (2560 x 1440) resolution
• H.265 video compression
• Built-in microphone and speaker
• Micro SD card slot (max. 512 GB)
• IP67 weatherproof rating
• 4G LTE connectivity
• Solar-powered with rechargeable battery

Specifications

• Image sensor: 1/3" CMOS
• Maximum resolution: 2560 (H) × 1440 (V)
• ROM: 128 MB
• RAM: 128 MB
• Scanning system: Progressive
• Electronic shutter: Auto/Manual 1/3 s–1/100,000 s
• Minimum illumination: 0.01 [email protected] (color, 30 IRE), 0.001 [email protected] (B/W, 30 IRE), 0 lux (with illumination on)
• S/N ratio: >40 dB
• Illumination range: 3.6 mm: up to 30 m (IR), up to 20 m (warm light)
• Illumination on/off control: Auto; Manual
• Number of illuminators: 1 (IR LED); 1 (warm light)
• Angle adjustment: Pan: 0° to 360°, Tilt: –60° to 0°, Rotation: 0° to 360°
• Lens type: Fixed focal
• Lens mount: M12
• Focal length: 3.6 mm
• Max. aperture: F1.6
• Field of view: 3.6 mm: H: 78.4°, V: 42.4°, D: 92.4°
• Aperture control: Fixed
• Minimum focus distance: 3.6 mm: 1.5 m
• DORI (Detect, Observe, Recognize, Identify): 3.6 mm: 78.0 m (Detect), 31.2 m (Observe), 15.6 m (Recognize), 7.8 m (Identify)
• Intelligence: SMD
• Video compression: H.265
• Video frame rate: Main stream: 2560 × 1440@(1–15 fps), sub stream: 640 × 360@(1–15 fps)
• Streaming capability: 2 streams
• Resolution: 4M (2560 × 1440), 3M (2048 × 1536), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
• Video bitrate: H.265: 32 kbps–4096 kbps
• Day/Night mode: Auto(ICR)/Color/B/W
• BLC: Yes
• HLC: Yes
• WDR: DWDR
• White balance: Auto
• Gain control: Auto
• Noise reduction: 3D NR
• Motion detection: OFF/ON (4 areas, rectangular)
• Smart Dual Light: Yes
• Privacy masking: 4 areas
• Built-in microphone: Yes
• Built-in speaker: Yes
• Audio compression: G.711a
• Alarm events: SD card error; SD card full; motion detection; PIR alarm; low battery level
• Network port: RJ-45 (10/100 Base-T)
• Network system: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (Europe, Middle East, Africa), FDD-LTE: B2/B3/B4/B5/B7/B8/B28/B66 (Latin America)
• SDK and API: Yes
• Interoperability: P2P
• Storage: Micro SD (max. 512 GB)
• Management software: DMSS; DSS Pro
• Mobile app: iOS; Android
• Certifications: CE-LVD: EN62368-1; CE-EMC; CE-RED
• USB port: 1 Port Type-C
• Power supply: 12 VDC
• Power consumption: Ultra power-saving mode: 0.036 W; Power-saving mode: 0.047 W; AOV mode: 0.26 W; Performance mode: 1.33 W
• Operating temperature: –30 °C to +60 °C
• Operating humidity: ≤95% (RH), non-condensing
• Storage temperature: –30 °C to +60 °C
• Storage humidity: ≤95% (RH), non-condensing
• Protection: IP67
• Housing material: Plastic
• Product dimensions: 256 mm × 290 mm × 197 mm (10.08" × 11.42" × 7.76")
• Net weight: 1357 g (2.99 lb)
• Gross weight: 2869 g (6.33 lb)
• Battery type: Lithium iron phosphate, capacity: 64 Wh, voltage: 6.4 V
• Battery life: Over 1,000 cycles
• Battery operating temperature: Charging: –30 °C to +60 °C, Discharging: –40 °C to +60 °C
• Solar module dimensions: 285 mm × 235 mm × 2.5 mm
• Maximum power: 10.5 W
• Cell type: Monocrystalline silicon
