DrayTek Vigor 2765ax-B VDSL2/ADSL2+ Modem Router Wi-Fi 6 AX1800 Dual-Band Gigabit

The DrayTek Vigor 2765ax-B is a high-performance VDSL2/ADSL2+ modem router with integrated Wi-Fi 6 (802.11ax) technology, designed for small businesses and demanding home users. It delivers combined wireless speeds of up to 1.8 Gbps (1.2 Gbps on 5 GHz + 574 Mbps on 2.4 GHz) and features dual-band connectivity, four Gigabit LAN ports, and a configurable WAN/LAN port for flexible internet access. With support for Annex B (used in Germany, Austria, Switzerland), it ensures compatibility with local DSL infrastructure.

Advantages

Experience ultra-fast Wi-Fi 6 speeds, reduced latency, and improved capacity for multiple devices. The Vigor 2765ax-B offers robust VPN capabilities (up to 16 tunnels), advanced security features including SPI firewall and WPA3, and multi-WAN failover/load balancing via DSL, Ethernet, or USB 3G/4G modem. Its compact design supports desktop or wall-mount placement.

Suitable for

• Small offices requiring reliable and secure internet connectivity
• Home users with multiple Wi-Fi devices seeking higher throughput
• Businesses needing VPN tunnels for remote access
• Users in Annex B regions (Germany, Austria, Switzerland)

Key specifications

• Wireless: Dual-band Wi-Fi 6 (802.11ax), AX1800 class
• WAN: 1x VDSL2/ADSL2+ (RJ-11), 1x Gigabit Ethernet (configurable as WAN2/LAN5), 1x USB 2.0 (for 3G/4G modem)
• LAN: 4x Gigabit Ethernet (RJ-45)
• VPN: Up to 16 tunnels (IPsec, PPTP, L2TP, L2TP over IPsec, SSL VPN)
• Security: SPI firewall, DoS/DDoS prevention, WPA3/WPA2/WPA, MAC filter, 802.1X
• Management: Web UI, CLI, TR-069, VigorACS 2
• Power: External DC 12V/1.5A

Recommendations

For optimal performance, pair with DrayTek's VigorACS 2 cloud management for centralized control. Use the USB port for 3G/4G backup or network storage. The router supports IPv6 and is ideal for upgrading existing DSL connections to Wi-Fi 6.
