DSIT CAT6 U/UTP Netzwerk-Installationskabel, 50m, Blau, 100% Kupfer, massiv, 23 AWG, 250MHz, Eca

Most budget CAT6 cables cut corners with copper-clad aluminium (CCA), but this DSIT reel uses 100% solid copper conductors—every metre of the 50-metre pull box delivers true CAT6 performance. The unshielded twisted pair (U/UTP) design keeps installation simple and cost-effective for indoor structured cabling, while the blue PVC jacket stands out in patch panels and cable trays.

Highlights

• CAT6 U/UTP, 4 pairs, solid 23 AWG conductors
• 100% copper (not CCA) for long-term signal integrity
• 50-metre pull box, ideal for multiple runs or a single long link
• 250 MHz bandwidth, meets TIA/EIA-568-C.2 and ISO/IEC 11801
• Eca fire rating for basic indoor use
• Blue jacket for quick visual identification

In daily use

Installers will appreciate the solid-core design, which holds its shape when punched down into keystone jacks or patch panels. The PVC jacket is durable yet flexible enough for routing through conduits and behind walls. Because the cable is unshielded, it is best suited for environments without high electromagnetic interference—typical offices, homes, and light commercial spaces. The 100% copper conductors ensure full Power over Ethernet (PoE) capability without the heat buildup seen in CCA cables.

Full specifications

• Category: CAT6
• Shielding: U/UTP (unshielded)
• Length: 50 metres
• Colour: Blue
• Conductor material: 100% copper
• Conductor type: Solid
• Conductor gauge: 23 AWG
• Number of pairs: 4
• Jacket material: PVC
• Max. bandwidth: 250 MHz
• Max. data rate (100m): 1 Gigabit Ethernet
• Max. data rate (short distances): 10 Gigabit Ethernet up to 55m
• Impedance: 100 Ohm
• Application: Indoor, data networks, Ethernet
• Connector type: Bulk cable (no connectors)
• Standards compliance: TIA/EIA-568-C.2, ISO/IEC 11801
• Fire rating (CPR class): Eca

Final note

For reliable Gigabit Ethernet and PoE over long runs, this solid-copper CAT6 cable is a dependable choice that avoids the pitfalls of CCA alternatives.
