DSIT STP CAT6a RJ45 konektor bez nástroja - tienený, 10G, Slim

10 Gigabit Ethernet over twisted pair demands uncompromising signal integrity—this toolless CAT6a RJ45 connector delivers up to 500 MHz bandwidth with full STP shielding, enabling reliable 10GBASE-T performance without specialised crimp tools.

Overview

The DSIT DC-RJ45-CAT6A-SLIM is a field-terminable RJ45 plug engineered for custom patch cable assembly in high-performance networks. Its zinc die-cast housing provides 360° shielding continuity, while the slim profile allows higher port density in patch panels and switches. Termination is achieved through an integrated IDC mechanism—no crimping tool required—making it ideal for on-site installations and quick repairs.

What stands out

• Tool-free IDC termination: strip, insert, and close—no crimp tool needed.
• Supports solid and stranded conductors from 22 to 26 AWG, with cable diameters 6.0–9.0 mm.
• Gold-plated contacts (50 µm) ensure low contact resistance and long-term corrosion resistance.
• Full PoE++ compatibility (IEEE 802.3af/at/bt) up to 90 W per port.
• Re-terminable: limited re-termination possible for corrections or reuse.

Technical details

• Connector type: RJ45 (8P8C) male
• Performance category: CAT6a (TIA/EIA-568-C.2, ISO/IEC 11801, EN 50173)
• Shielding: STP (shielded twisted pair) with zinc die-cast housing
• Bandwidth: up to 500 MHz
• Data rate: up to 10 Gbps (10GBASE-T)
• Wire compatibility: solid and stranded, 22–26 AWG
• Cable outer diameter: 6.0–9.0 mm
• Contact plating: gold, 50 µm
• Housing material: zinc die-cast (shield), PC (plastic)
• PoE support: PoE, PoE+, PoE++ (IEEE 802.3af/at/bt)
• Compliance: RoHS, REACH

Our verdict

A robust, installer-friendly connector that brings CAT6a performance to field termination—perfect for data centres, enterprise cabling, and custom patch leads where tool-free speed and slim density matter.
