EFB SC simplex optická spojka OM1/2, béžová, keramické puzdro

The EFB SC Simplex Fiber Optic Coupler is a high-quality, one-piece adapter designed for reliable connections in multimode fiber networks. It supports OM1 and OM2 fiber types, making it ideal for both legacy and current installations. The ceramic sleeve ensures low insertion loss and high return loss, providing stable performance over many mating cycles.

Advantages

This coupler offers exceptional durability with over 500 mating cycles, low insertion loss of less than 0.3 dB, and high return loss exceeding 30 dB. Its beige housing color indicates multimode compatibility, simplifying identification in patch panels. The one-piece design enhances mechanical stability and ease of installation.

Suitable for

• Multimode fiber optic networks (OM1/OM2)
• SC-to-SC connections in patch panels and wall outlets
• Data centers, telecommunications rooms, and LAN applications
• Simplex fiber optic links requiring reliable coupling

Key specifications

• Connector Type: SC (both ports)
• Fiber Mode: Multimode
• Fiber Compatibility: OM1, OM2
• Configuration: Simplex
• Sleeve Material: Ceramic
• Housing Color: Beige
• Design: One-piece
• Mounting Type: Panel Mount
• Insertion Loss (Typical): < 0.3 dB
• Return Loss (Typical): > 30 dB
• Mating Durability: > 500 cycles
• Operating Temperature Range: -20°C to +70°C
• Storage Temperature Range: -40°C to +85°C
• Housing Material: Plastic
• Standards Compliance: IEC 61754-4 (SC Connector Interface)

Recommendations

For optimal performance, use with multimode patch cables (OM1/OM2) and ensure clean fiber end-faces before mating. This coupler is suitable for indoor installations where reliable, low-loss connections are required.
