EFB Elektronik PLC rozbočovač 1:32 SC/APC 9/125µm G.657.A1 LSZH

The EFB Elektronik PLC Splitter 1:32 SC/APC is a high-performance planar lightwave circuit splitter designed for FTTH and FTTx networks. It splits a single optical input into 32 outputs with low insertion loss and high uniformity, ensuring reliable signal distribution. The splitter features a 1.0m bare fiber pigtail input and SC/APC connectors on the output, with bend-insensitive G.657.A1 single-mode fiber and a durable LSZH jacket for safety.

Advantages

Low insertion loss (≤17.5 dB) and high return loss (≥55 dB) ensure excellent signal quality. Compact and robust design with Telcordia GR-1209/1221 compliance guarantees long-term reliability. LSZH jacket provides enhanced safety in confined spaces.

Suitable for

• FTTH (Fiber to the Home) networks
• FTTx (Fiber to the x) deployments
• Passive Optical Networks (PON)
• Fiber optic distribution in data centers and telecom rooms

Key specifications

• Split Ratio: 1:32
• Input Connector: None (Bare Fiber Pigtail, 1.0m)
• Output Connector: SC/APC
• Fiber Type: Single-mode G.657.A1 (Bend-Insensitive)
• Core/Cladding Diameter: 9/125 µm
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Operating Wavelength: 1260-1650 nm
• Max. Insertion Loss: ≤ 17.5 dB
• Return Loss (APC): ≥ 55 dB
• Uniformity: ≤ 1.5 dB
• PDL: ≤ 0.3 dB
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -40°C to +85°C
• Compliance: RoHS, Telcordia GR-1209, GR-1221

Recommendations

For optimal performance, use with compatible SC/APC patch cables and ensure proper handling of the bare fiber pigtail. Ideal for high-density fiber distribution in FTTH applications.
