Elo Touch Solutions 2703LM 27" Medical Grade Full HD LED monitor s PCAP dotykom

The Elo Touch Solutions 2703LM is a medical-grade 27-inch LED monitor engineered for demanding clinical environments. With its certified compliance to IEC/UL/EN 60601-1 (3rd Edition), this display is purpose-built for use in patient care areas, offering both safety and reliability. The Full HD resolution and projected capacitive touch deliver crisp visuals and responsive interaction, making it an ideal choice for medical imaging, patient monitoring, and healthcare kiosks.

Highlights

• 27-inch Full HD (1920x1080) TFT Active Matrix LCD
• Projected Capacitive (PCAP) touch with 10-point multi-touch
• Medical-grade certifications: IEC 60601-1, UL 60601-1, EN 60601-1 (3rd Edition)
• Zero-bezel design with anti-glare surface
• VESA mount compatible (100x100mm)
• Multiple video inputs: HDMI, DisplayPort, VGA

In daily use

The 2703LM is designed to withstand the rigors of healthcare settings. Its anti-glare screen ensures visibility under bright clinical lighting, while the zero-bezel design facilitates easy cleaning and infection control. The 10-point touch capability allows for intuitive interaction, whether navigating electronic medical records or zooming into high-resolution images. With a brightness of 250 cd/m² and a contrast ratio of 1000:1, the display delivers clear, detailed imagery essential for accurate diagnosis.

Full specifications

• Display Size: 27 inches (68.58 cm)
• Native Resolution: 1920 x 1080 (Full HD)
• Touch Technology: Projected Capacitive (PCAP)
• Multi-Touch Points: 10-point
• Aspect Ratio: 16:9
• Brightness: 250 cd/m² (typical)
• Contrast Ratio: 1000:1 (typical)
• Response Time: 14 ms (typical)
• Viewing Angle: 178° H / 178° V
• Video Input Ports: 1x HDMI, 1x DisplayPort, 1x VGA
• Touch Interface: 1x USB Type-B
• VESA Mounting: 100 x 100 mm
• Panel Type: TFT Active Matrix LCD
• Surface Treatment: Anti-glare
• Bezel Design: Zero-bezel
• Power Consumption: 20W (typical)
• Operating Temperature: 0°C to 40°C (32°F to 104°F)

Final note

The Elo 2703LM combines medical-grade safety with advanced touch technology, ensuring reliable performance in critical environments. Its robust feature set and compliance make it a trusted choice for healthcare professionals.
