ELTAKO FT4GF/8-24VUC-sz rádiový tlačidlový spínač, čierny, s jednoduchou a dvojitou kolískou 30000984

Conventional wired switches often limit flexibility in modern building automation. The ELTAKO FT4GF/8-24VUC-sz solves this by providing a battery-free wireless push-button that transmits commands via radio, eliminating the need for complex wiring and enabling control of lighting, blinds, and scenes from any location.

Who is it for

This wireless push-button is ideal for electricians, system integrators, and homeowners seeking a reliable, flexible control interface for ELTAKO wireless systems. It suits renovation projects where adding new wiring is impractical, as well as new installations requiring versatile multi-channel control without batteries.

Main features

• Four independent channels for switching, dimming, blind control, or scene activation.
• Operates on 8-24V UC (AC/DC), compatible with common low-voltage supplies.
• Uses ELTAKO wireless protocol at 868.3 MHz with up to 100 m outdoor range.
• Includes both a single rocker and a double rocker for flexible configuration.
• Flush-mounted design fits standard 55mm switch systems, with high-gloss black thermoplastic finish.
• Battery-free: energy is harvested from the actuation, ensuring maintenance-free operation.
• IP20 rated for indoor use, operating temperature -20°C to +50°C.

Specifications

• Product type: Wireless push-button / radio switch
• Number of channels: 4
• Colour: Black
• Supply voltage: 8-24V UC (AC/DC)
• Wireless technology: Eltako-Funk
• Wireless frequency: 868.3 MHz
• Transmission power: Max. 10 mW
• Indoor range: Up to 30 m
• Outdoor range: Up to 100 m
• Mounting type: Flush-mounted (55mm switch systems)
• Included rockers: 1x single rocker, 1x double rocker
• Material: Thermoplastic, high-gloss
• Protection class: IP20
• Operating temperature: -20°C to +50°C
• Functions: Switching, dimming, blind control, scene control

Tips

Pair the push-button with compatible ELTAKO actuators and receivers. For optimal range, avoid mounting near large metal objects or sources of interference. The double rocker can be used to control two separate functions on a single channel, such as open/close for blinds.
