Equip Cat.6A nemecký modulárny kryt

The Equip Cat.6A Modular Faceplate (model 125772) is a compact wall-mounted outlet with a shielded RJ45 socket designed for Cat.6A cabling. Finished in white and measuring 80 mm × 80 mm × 38.2 mm, this faceplate is compatible with equip® Back Box 125561 and intended for reliable high-speed ethernet connections in residential and commercial installations.

Advantages

The faceplate provides a robust, solid construction with a shielded RJ45 port to reduce interference and support Cat.6A performance. Its compact dimensions and standard mounting make it easy to install into common back boxes. The neutral white colour integrates with most interiors while the product weight of 0.17 kg keeps it lightweight for handling and fitting.

Suitable for

• Installations requiring Cat.6A Ethernet connectivity
• Residential and office network outlets
• Use with equip® Back Box 125561

Key specifications

• Model: 125772
• Connector: Shielded RJ45 socket
• Category support: Cat.6A
• Dimensions (W×H×D): 80 mm × 80 mm × 38.2 mm
• Package dimensions: 95 mm × 89 mm × 245 mm
• Colour: White
• Weight: 0.17 kg
• Compatible back box: equip® 125561

How to use

Mount the faceplate onto a compatible back box (e.g., equip® 125561) following standard electrical and cabling safety procedures. Terminate the Cat.6A cable to the shielded RJ45 module according to the appropriate wiring scheme, secure the module in the faceplate, and fasten the faceplate to the back box. Test the link with suitable network test equipment to verify correct termination and performance.

Recommendations

For optimal performance, use certified Cat.6A cabling and ensure the shield is properly connected to grounding at the installation point. Verify compatibility with the intended back box dimensions before installation.
