Industrial environments demand computing that can withstand extreme temperatures, vibration, and dust while delivering reliable performance. The Lenovo 5WS1F14343 is a rugged fanless edge computer engineered for continuous operation in harsh conditions, from factory floors to outdoor kiosks. Powered by an Intel Core i7-1185GRE processor with 32GB of ECC memory and a 1TB NVMe SSD, it handles real-time data processing, machine vision, and IoT gateway duties without throttling. Its sealed aluminum chassis and MIL-STD-810H certification ensure resilience against shock, vibration, and humidity, while the -20°C to 60°C operating range eliminates the need for active cooling.

Who is it for

This system is ideal for system integrators, industrial automation engineers, and IoT solution providers deploying edge computing in factories, transportation, smart retail, or outdoor installations. It suits applications requiring 24/7 uptime, such as SCADA, digital signage, robotics control, and edge AI inference, where dust, temperature swings, or vibration would cripple standard PCs.

Main features

• Fanless and ventless design with IP50 ingress protection prevents dust ingress and enables silent operation in noise-sensitive areas.
• Dual 2.5GbE ports and Wi-Fi 6E provide high-speed, redundant network connectivity for industrial protocols and cloud sync.
• Wide 12-24V DC power input with terminal block supports direct connection to industrial power sources, including vehicle batteries.
• Flexible mounting via DIN rail, wall, or VESA brackets simplifies integration into control cabinets or behind displays.
• TPM 2.0 and Kensington lock slot safeguard sensitive data and deter physical theft in public or unsecured locations.

Specifications

• Processor: Intel Core i7-1185GRE (4 cores, 8 threads, up to 4.4 GHz)
• Memory: 32GB DDR4-3200 ECC SODIMM (2x 16GB)
• Storage: 1TB NVMe PCIe Gen4 SSD
• Operating system: Windows 10 IoT Enterprise LTSC 2021
• Graphics: Intel Iris Xe Graphics
• Network: 2x 2.5GbE RJ-45, Wi-Fi 6E, Bluetooth 5.2
• Expansion: M.2 slots for SSD, Wi-Fi, and optional 5G WWAN
• I/O: 4x USB 3.2 Gen 2, 2x USB 2.0, 2x RS-232/422/485, 2x HDMI 2.0, 1x DisplayPort 1.4
• Power: 12-24V DC terminal block
• Operating temperature: -20°C to 60°C
• Certifications: MIL-STD-810H, IP50
• Cooling: Fanless
• Material: Aluminum alloy

Tips

For maximum reliability in dusty environments, mount the unit vertically to prevent particle accumulation on connectors. When using the optional 5G module, ensure the antenna is placed outside any metal enclosure to maintain signal strength. The ECC memory is particularly valuable for mission-critical data logging where memory errors cannot be tolerated.
