Gesipa 1830753 ručný nitovací prístroj pre slepé nity do 5 mm hliník / 4 mm oceľ

Manual hand riveting tool with lever action, handling aluminium blind rivets up to 5.0 mm diameter and steel or stainless steel up to 4.0 mm. Die-cast aluminium body with steel lever and spring-loaded ergonomic handle.

Overview

The Gesipa 1830753 is a compact manual riveting tool for blind rivets. It uses a lever action with a stroke length of approximately 8 mm. The body is made of high-quality die-cast aluminium, and the lever is steel. The handle is ergonomic and spring-loaded, providing automatic mandrel ejection.

What stands out

• Compatible with aluminium blind rivets up to 5.0 mm diameter
• Compatible with steel and stainless steel blind rivets up to 4.0 mm diameter
• Includes nosepieces for 2.4 mm, 3.0/3.2 mm, 4.0 mm, and 4.8/5.0 mm rivets
• Nosepieces stored in the tool body
• Automatic mandrel ejection via spring-loaded handle

Technical details

• Tool type: Manual hand riveting tool
• Rivet type compatibility: Blind rivets
• Rivet material compatibility: Aluminium up to 5.0 mm, steel up to 4.0 mm, stainless steel up to 4.0 mm
• Operating principle: Lever action
• Stroke length: Approximately 8 mm
• Body material: High-quality die-cast aluminium
• Lever material: Steel
• Handle design: Ergonomic, spring-loaded
• Mandrel ejection: Automatic (spring-loaded handle)
• Nosepiece sizes included: 2.4 mm, 3.0/3.2 mm, 4.0 mm, 4.8/5.0 mm
• Nosepiece storage: Integrated in tool body

Our verdict

A reliable manual riveter for light-duty general riveting tasks, with a compact design and easy handling.
