Grothe tlačidlo zvončeka 1-násobné 62000 nerez 24 V/1,5 A

The Grothe 62000 is a flush-mounted bell push button with a single stainless steel button, built for doorbell systems, access control, and intercoms. Its square stainless steel front plate measures 80 x 80 mm and suits standard flush-mounted boxes, while the screw terminals allow straightforward connection. The momentary contact switch handles up to 1.5 A at 24 V AC/DC, making it compatible with common bell transformers and control circuits.

Highlights

• Single stainless steel button, square design
• Flush-mounted installation with 80 x 80 mm front plate
• Momentary contact (normally open)
• Rated for 24 V AC/DC, max. 1.5 A switching current
• Screw terminal connection

In daily use

Press the button to trigger a doorbell, chime, or access control relay. The stainless steel surface is durable and easy to clean, and the flush-mounted design keeps the button nearly flat against the wall. With no illumination, the button remains discreet and relies on its clean metallic look.

Full specifications

• Product type: Bell push button
• Number of buttons: 1
• Material: Stainless steel
• Operating voltage: 24 V AC/DC
• Max. switching current: 1.5 A
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Design: Square
• Contact type: Momentary (normally open)
• Front plate dimensions (L x W): 80 x 80 mm
• Installation depth: approx. 20 mm

Final note

A reliable stainless steel bell push button for flush-mounted installations, rated for 24 V AC/DC and 1.5 A.
