Hager K67H podlahový káblový kanál 110 mm svetlosivá 2 m

In commercial offices and industrial facilities, the Hager K67H floor cable duct keeps power and data cables protected and neatly organized. This 2-metre duct features two chambers and a light grey PVC construction, suitable for walkable areas and light vehicle traffic.

Key specifications

• Length: 2000 mm
• Width: 110 mm
• Height: 20 mm
• Material: PVC
• Colour: Light grey (RAL 7035)
• Number of chambers: 2
• Protection class: IP40
• Impact resistance: IK07
• Operating temperature: -5 °C to +60 °C
• Halogen-free: No
• Lead-free: Yes
• Mounting type: Floor, screwable
• Application area: Indoor, commercial, industrial, residential
• Load bearing capacity: Walkable, suitable for light vehicle traffic
• Fire behaviour: Self-extinguishing
• Standards compliance: EN 50085-2-2

Why choose it

The K67H provides a robust solution for routing cables across floors without compromising safety or aesthetics. Its self-extinguishing PVC material and IK07 impact resistance ensure durability in high-traffic environments.

Ideal use cases

• Office spaces with open floor plans
• Retail environments needing temporary power distribution
• Industrial workshops with light vehicle movement
• Residential areas where floor-level cable management is required

Good to know

The duct is screwable for secure installation and complies with EN 50085-2-2 for cable trunking systems. It is not halogen-free, so consider ventilation requirements in enclosed spaces.
