HAGER koncový diel bezhalogénový pre LF/LFH 60x90mm dopravná biela (RAL 9016) LF6009069016

The HAGER LF6009069016 End Piece is a high-quality, halogen-free end cap designed specifically for OBO Bettermann LF/LFH cable trunking systems. It provides a clean, professional finish to open trunking ends, ensuring safety and compliance in commercial, industrial, and residential installations. Manufactured from durable PC/ABS material, this end piece offers excellent impact resistance (IK07) and UV stability, making it suitable for long-term use in demanding environments.

Advantages

Halogen-free material reduces toxic smoke emission in case of fire, enhancing safety. Tool-free snap-on installation saves time and labor. The traffic white (RAL 9016) color blends seamlessly with standard trunking. Self-extinguishing and low smoke properties meet stringent fire safety standards.

Suitable for

• Closing open ends of LF/LFH cable trunking systems (60x90mm)
• Commercial and office buildings requiring halogen-free components
• Industrial facilities where fire safety and low smoke emission are critical
• Residential projects demanding high-quality trunking accessories

Key specifications

• Product Type: End Piece / End Cap
• System Compatibility: OBO Bettermann LF/LFH Cable Trunking System
• Trunking Dimensions (H x W): 60 x 90 mm
• Material: PC/ABS (Polycarbonate/Acrylonitrile Butadiene Styrene)
• Halogen-Free: Yes
• Color: Traffic White (RAL 9016)
• Mounting Method: Snap-on / Clip-on (tool-free)
• Fire Behavior: Low smoke emission, self-extinguishing
• UV Stability: Yes
• Temperature Range (Operating): -25°C to +60°C
• Impact Resistance: IK07
• Surface Finish: Smooth, Matt
• RoHS Compliant: Yes
• REACH Compliant: Yes
• Protection Class: IP30 (when installed correctly with trunking)
• Certifications: VDE
• Quantity per Pack: 1 piece

Recommendations

For best results, use with HAGER or OBO Bettermann LF/LFH trunking systems. Ensure trunking ends are clean and free of debris before installation. This end piece is designed for indoor use only.
