Hager M5848 PVC káblový kanál čierny 40x25mm 2m

The Hager M5848 is a high-quality PVC cable trunking (wiring duct) designed for professional cable management in electrical installations. Manufactured by Hager, part of the Tehalit.LFG series, this trunking provides a reliable and tidy solution for routing and protecting cables in indoor environments. With a sleek black finish (RAL 9005), it blends seamlessly into various settings.

Advantages

This cable trunking offers easy clip-on cover installation, allowing quick access to cables for maintenance or modifications. Its self-extinguishing PVC material ensures safety in case of fire, while the IP40 protection rating guards against solid objects larger than 1 mm. The trunking is screwable and wall-mountable, providing secure fixing. With a length of 2 meters and an internal cross-section of 7.56 cm², it accommodates multiple cables neatly.

Suitable for

• Electrical installations in commercial and residential buildings
• Routing power and data cables along walls or ceilings
• Industrial control panels and automation systems
• Office environments requiring organized cable management

Key specifications

• Brand: Hager
• Model: M5848
• Material: PVC (Polyvinyl Chloride)
• Colour: Black (RAL 9005)
• External Width: 40 mm
• External Height: 25 mm
• Length: 2000 mm (2 m)
• Number of Compartments: 1
• Cover Type: Clip-on
• Mounting Type: Screwable / Wall-mountable
• Halogen-free: No
• Self-extinguishing: Yes
• Operating Temperature Range: -5°C to +60°C
• Protection Class: IP40
• Internal Cross-Section Area: 7.56 cm²
• Impact Resistance: IK07
• Compliance: RoHS, CE

Recommendations

For optimal installation, use appropriate screws and wall plugs (not included). Ensure the trunking is securely fixed to a clean, dry surface. This product is suitable for indoor use only.
