HAGER WNA021 osvetlený tlačidlový spínač s prepínacím kontaktom, séria W.1, polárna biely

The HAGER WNA021 stands out with its integrated LED illumination, making the switch easy to locate in dark hallways or staircases while adding a subtle visual indicator of its status. Unlike standard mechanical push-buttons, this model combines a momentary action with a changeover contact, offering flexible control for lighting circuits, doorbells, or pulse relays.

Highlights

• Integrated LED illumination for clear visibility and status indication
• Changeover (SPDT) contact supports versatile switching configurations
• Flush-mounted design fits standard wall boxes for a clean, seamless look
• Part of the Hager W.1 series, ensuring compatibility with matching cover plates and frames
• Halogen-free thermoplastic construction in polar white (RAL 9010) for durability and a neutral appearance

In daily use

Ideal for residential and commercial applications, the WNA021 provides a reliable momentary contact that returns to its rest position after actuation. The screw terminals accept rigid conductors from 1.5 to 2.5 mm², ensuring secure connections. Rated for 250 V AC and 10 A, it handles typical lighting loads with ease. The operating temperature range of -5 to +40 °C makes it suitable for most indoor environments.

Full specifications

• Switch type: Push-button (momentary)
• Contact configuration: Changeover (SPDT)
• Rated voltage: 250 V AC
• Rated current: 10 A
• Connection type: Screw terminals
• Mounting type: Flush-mounted
• Design line: Hager W.1
• Material: Halogen-free thermoplastic
• Colour: Polar White (RAL 9010)
• Number of rockers: 1
• Terminal capacity: 1.5 – 2.5 mm² rigid conductors
• Operating temperature: -5 to +40 °C

Final note

The WNA021 requires a Hager W.1 cover plate and frame for a complete installation, allowing you to match the surrounding décor while enjoying the benefits of illuminated control.
