HANWHA VISION SBV-136B prípojná krabica pre WiseNet HD+ kamery - hliník - čierna - IP66 IK10

The HANWHA VISION SBV-136B is a high-quality junction box designed for use with Hanwha Techwin WiseNet HD+ fixed dome cameras. Crafted from durable aluminum with a powder-coated finish, this enclosure provides robust protection for your surveillance system. With IP66 and IK10 ratings, it is suitable for both indoor and outdoor applications, ensuring reliable performance in harsh environments.

Advantages

This junction box offers exceptional durability and weather resistance, making it ideal for demanding security installations. Its vandal-resistant design (IK10) protects against impact, while the IP66 rating ensures protection against dust and water jets. The aluminum construction and powder-coated finish provide long-lasting corrosion resistance.

Suitable for

• Hanwha WiseNet HD+ HCV-6070, HCV-6080, SCV-6023, SCV-6083 fixed dome cameras
• Indoor and outdoor surveillance installations
• Surface mount applications requiring a secure and weatherproof enclosure

Key specifications

• Product Type: Dome Housing / Enclosure
• Housing Material: Aluminum
• Dome Cover Material: Polycarbonate
• Color: Black
• Ingress Protection: IP66
• Impact Protection: IK10
• Mounting Type: Surface Mount
• Operating Temperature: -30°C to 55°C (-22°F to 131°F)
• Operating Humidity: 0% to 90% RH (non-condensing)
• Finish: Powder Coated
• Certifications: CE, FCC, KC

Recommendations

For optimal performance and protection, pair this junction box with compatible Hanwha WiseNet HD+ cameras. Ensure proper surface mounting and sealing to maintain IP66 integrity.
