HEINRICH KOPP Schuko sieťový konektor samec biely 16A 250V skrutkové svorky 402629005

Rated for 16 A at 250 V AC, this Schuko power plug handles demanding indoor loads with screw terminals that accept up to 2.5 mm² conductors.

Overview

The HEINRICH KOPP 402629005 is a conventional white Schuko plug (Type F, CEE 7/4) with 2 poles and earth. It is designed for universal compatibility with devices that require a Schuko connection. The straight cable entry accommodates cables with a diameter of 6–13 mm, and the thermoplastic housing provides durable insulation for indoor use.

What stands out

• 16 A / 250 V rating for high-power appliances
• Screw terminals for secure, reliable wiring
• Straight cable entry fits cable diameters 6–13 mm
• Brass contacts ensure good conductivity
• VDE and CE certified

Technical details

• Product type: Power plug
• Plug standard: Schuko (Type F, CEE 7/4)
• Number of poles: 2P+E
• Colour: White
• Rated voltage: 250 V AC
• Rated current: 16 A
• Connection type: Screw terminals
• Cable entry: Straight
• Housing material: Thermoplastic
• Protection class: IP20
• Max. cable cross-section: 2.5 mm²
• Cable diameter range: 6–13 mm
• Mounting type: Cable mount
• Contact material: Brass
• Application environment: Indoor use

Our verdict

A robust Schuko plug for indoor power connections up to 16 A, with easy screw-terminal installation and a straight cable entry.
