HP Aruba J4860D SFP (Mini-GBIC) transceiver modul - Gigabit Ethernet 1000Base-LH - LC Single-Mode - 70 km

The HP Aruba J4860D is a high-performance SFP (Mini-GBIC) transceiver module designed for long-haul Gigabit Ethernet connections over single-mode fiber. It supports 1000Base-LH standard, delivering reliable data transmission up to 70 km. This hot-pluggable module features an LC single-mode connector and operates at a wavelength of 1550 nm, making it ideal for extended reach applications in enterprise networks.

Advantages

Extended reach up to 70 km over single-mode fiber, hot-swappable design for minimal downtime, and low power consumption (<1W) ensure efficient and flexible network expansion. Digital Diagnostics Monitoring (DDM) provides real-time performance tracking.

Suitable for

• HPE Aruba 2930F, 2930M, 6300, 6400, 7200, and 8300 Series Switches
• Long-distance fiber optic links in campus or data center networks
• Gigabit Ethernet backbone connections requiring reliable single-mode transmission

Key specifications

• Device Type: Transceiver module
• Form Factor: SFP (Mini-GBIC)
• Connectivity Technology: Wired
• Cabling Type: Fiber optic
• Data Link Protocol: Gigabit Ethernet
• Data Transfer Rate: 1 Gbps
• Optical Wavelength: 1550 nm
• Max Transfer Distance: 70 km
• Optical Connector Type: LC single-mode
• Fiber Type: Single-mode fiber (SMF)
• Duplex Mode: Full-duplex
• Interface: 1 x 1000Base-LH
• Standards Compliance: IEEE 802.3z
• Hot Swappable: Yes
• Digital Diagnostics Monitoring (DDM): Yes
• Power Consumption (Typical): <1W
• Operating Temperature: 0°C to 70°C

Recommendations

For optimal performance, use with compatible HPE Aruba switches and single-mode fiber optic cables. Ensure proper handling and insertion to maintain signal integrity.
