Hybridný menič ULTRA HYBRID 7500 48/230V

The Hybrid Inverter ULTRA HYBRID 7500 48/230V is a high-performance solar inverter designed for residential and commercial energy storage systems. It combines solar charging, battery charging, and AC output in one unit, providing reliable backup power and maximizing self-consumption of solar energy.

Advantages

This inverter offers seamless transition between grid and battery power, high efficiency, and advanced MPPT technology for optimal solar harvesting. Its dual MPPT trackers allow flexible PV array configurations, while the pure sine wave output ensures compatibility with sensitive electronics.

Suitable for

• Off-grid and grid-tied solar systems with battery storage
• Backup power for homes and small businesses
• Self-consumption optimization of solar energy

Key specifications

• Rated Power: 7500W
• Peak Power: 15000VA (5 seconds)
• Battery Voltage: 48V DC
• Output Voltage: 230V AC
• Output Waveform: Pure Sine Wave
• Output Frequency: 50/60Hz (Auto Sensing)
• Max PV Array Power: 8000W
• Max PV Input Voltage (VOC): 500V DC
• MPPT Voltage Range: 120-450V DC
• Number of MPPT Trackers: 2
• Max Solar Charge Current: 160A
• Max AC Charge Current: 120A
• Max Total Charge Current: 160A
• Efficiency (Peak): 93%
• Transfer Time: 10ms (UPS mode), 20ms (Appliance mode)
• Communication Ports: RS232, USB, CAN, Dry Contact
• Protection Features: Overload, Short Circuit, Over Temperature, Over/Under Voltage
• Operating Temperature: -10°C to 50°C

Recommendations

For optimal performance, pair this inverter with a compatible 48V battery bank and ensure proper ventilation. Consult a certified installer for system design and installation.
