I/O modul bleBox shutterBoxDC 2x binárne vstupy, 2x reléové výstupy 230V

The bleBox shutterBoxDC is a compact Wi‑Fi I/O module designed for controlling shutters, blinds and other mains-powered devices. It offers two binary inputs for external switch or pulse signals and two relay outputs capable of switching 230 V loads. The device integrates with home automation systems and bleBox apps to allow remote control, timed actions and automation rules. Its small footprint and straightforward wiring make it suitable for installation in junction boxes, control cabinets or behind switches.

Advantages

The module enables wireless control of 230 V actuators while retaining local manual input through the two binary inputs. Relay outputs provide reliable switching for motors or lighting circuits, and the Wi‑Fi connection removes the need for separate control wiring. The design supports easy integration into automation scenarios, offering configurable responses to input signals and scheduled operations. Installation is simplified by clear terminal labeling and a compact enclosure suited for concealed mounting.

Suitable for

• Control of roller shutters and blinds with 230 V motors
• Lighting circuits and other mains-powered devices requiring relay switching
• Integration into smart home systems for remote or automated control
• Use in junction boxes, behind wall switches or within small control cabinets

Key specifications

• Connectivity: Wi‑Fi for wireless control and integration
• Inputs: 2 binary inputs for external switches or pulse signals
• Outputs: 2 relay outputs rated for switching 230 V AC loads
• Mounting: compact enclosure suitable for installation in junction boxes or behind switches
• Control: supports local manual control and remote control via compatible apps and automation rules

How to use

Connect the module to the mains supply and wire the two relay outputs to the target 230 V devices following safety standards. Attach external switches or sensors to the binary inputs to provide manual or pulse control. Use the bleBox mobile or web application to add the device to your Wi‑Fi network, configure input behaviour, assign actions to relay outputs and set timers or automation rules. Verify correct wiring and test each function after installation to ensure safe operation.

Recommendations

Ensure installation is performed by a qualified electrician and disconnect mains power before wiring. Use the module within its rated voltage and load limits, and protect motor loads with appropriate overload protection. For reliable Wi‑Fi operation, place the device where it can receive a stable wireless signal or use a Wi‑Fi extender if needed.
