Jednotka rozvodu napájania Bachmann 331.0202

Power Distribution Unit Bachmann 331.0202 is a 1U rack-mountable power distribution unit designed for standard 19" racks. It is constructed from aluminium and equipped with a 2.0 m H05VV-F 3G 1.50 mm2 grey power cable with a moulded right-angle plug featuring a dual earthing contact system. The unit provides five white socket outlets set at a 35° angle, includes mounting brackets, and incorporates overvoltage protection as well as mains and frequency filters.

Advantages

The Bachmann 331.0202 offers compact 1U rack integration and an aluminium housing for durable installation. Its angled sockets (35°) improve cable routing in dense racks, while the dual-earthing right-angle plug and included mounting brackets simplify safe installation. Built-in overvoltage protection together with mains and frequency filters helps protect connected equipment from voltage spikes and electrical noise.

Suitable for

• Server rooms and data centers requiring rack-mounted power distribution
• Network cabinets and 19" rack enclosures
• Equipment racks where angled outlets improve cable management
• Applications needing basic overvoltage protection and filtering

Key specifications

• Model: Bachmann 331.0202
• Form factor: 1U, fits 19" racks
• Housing: aluminium
• Power input cable: 2.0 m, H05VV-F 3G 1.50 mm2, grey, moulded right-angle plug with dual earthing contact
• Socket outlets: 5 × with earthing contact, white, set at 35°
• Protection and filtering: overvoltage protection plus mains and frequency filters
• Mounting: brackets included
• Brand: Bachmann
• MPN: 331.0202
• EAN: 4016514008124

How to use

Install the Bachmann 331.0202 into a standard 19" rack using the supplied mounting brackets, ensuring the unit occupies a 1U space. Connect the moulded right-angle power plug to a suitable grounded mains outlet and route connected device cables to the five angled socket outlets. Verify earthing continuity and ensure connected equipment does not exceed the unit's rated capacity. Follow site electrical safety procedures when installing or servicing.

Recommendations

Position the unit to allow clear access to angled outlets for easier cable routing; avoid overloading the combined outlets and periodically inspect the overvoltage protection and cable condition for signs of wear.
