JUNG 211 GDE otočný spínač, metallic finish, 230–240 V AC, 50 Hz

JUNG 211 GDE is a wall-mounted rotary switch with a metallic finish designed for direct control of AC mains circuits. It operates at 230–240 V AC, 50 Hz, and provides manual selection and switching via a rotary actuator. The device is intended for installation in a standard appliance box according to DIN 49073 and is suitable for switching and dimming incandescent and high-voltage halogen lamps, as well as for straightforward control tasks in household and commercial electrical installations.

Advantages

The rotary construction offers tactile, reliable manual control and a clear switching position. The metallic finish provides enhanced mechanical robustness and an appearance compatible with modern interior fittings. Designed for installation in a standard appliance box, the device simplifies replacement and integration into existing wiring schemes. The product supports mixed operation within the specified output limits, enabling use with resistive and inductive loads where appropriate.

Suitable for

Key specifications

How to use

Install the rotary switch into a compatible appliance box following local electrical codes and the mounting standard DIN 49073. Connect the mains supply and the load conductors according to the circuit diagram and ensure power is isolated before wiring. After installation, use the rotary actuator to select the desired on/off or intermediate positions for switching or dimming compatible lamps and loads. Verify correct operation at nominal voltage and test under expected load conditions.

Recommendations

Use the switch within its rated supply voltage and observe the load type and power limits for mixed operation. For dimming applications, confirm that the connected lamps are compatible with rotary-dimming control and that wiring and protective devices conform to applicable standards. If used for motor control, ensure the motor and drive arrangement are suitable for manual rotary switching and include additional protection where required.
