JUNG 2194REGHM univerzálny stmievač, DIN lišta, 250-400 V, biela

The JUNG 2194REGHM universal dimmer stands apart from typical DIN-rail dimmers by combining automatic load detection with manual phase-cut selection, ensuring stable operation across incandescent, halogen, and dimmable LED lamps without flicker. Its 3-module width houses a robust 500 W/VA capacity, making it suitable for both residential and light commercial lighting circuits.

Highlights

• Universal dimming for incandescent, HV halogen, LV halogen (electronic or conventional transformer), and dimmable LEDs
• Automatic or manual selection of leading/trailing edge phase control
• High load capacity: up to 500 W for resistive loads, 500 VA for inductive/capacitive loads, and 100 W/VA for LEDs
• Conventional push-button control with 230 V AC input
• Compact DIN rail mounting (3 modules, 52.5 mm wide)
• Low standby loss of approximately 0.5 W

In daily use

Installation is straightforward on standard 35 mm DIN rails in distribution boards. The dimmer automatically recognises the connected load type and selects the appropriate dimming principle, but can also be manually set via a rotary switch. Push-buttons connected to the control input allow smooth dimming and switching. The device is protected against overload and short circuits, and its IP20 rating suits dry indoor environments.

Full specifications

• Brand: JUNG
• Model: 2194REGHM
• MPN: 2194REGHM
• EAN: 4011377150942
• Product type: Universal dimmer
• Mounting: DIN rail (REG)
• Operating voltage (load): 230 V AC, 50/60 Hz
• Control input voltage: 230 V AC
• Max. incandescent/halogen load: 500 W
• Max. LV halogen (electronic transformer): 500 VA
• Max. LV halogen (conventional transformer): 500 VA
• Max. dimmable LED load (RC mode): 100 W
• Max. dimmable LED load (RL mode): 100 VA
• Min. load: 20 W (incandescent/halogen), 3 W (LED)
• Dimming principle: Phase cut (leading/trailing edge, automatic/manual)
• Control method: Push-button (conventional)
• Standby loss: approx. 0.5 W
• Protection class: IP20
• Ambient temperature: -5 °C to +45 °C
• Number of modules: 3 TE
• Colour: White

Final note

The JUNG 2194REGHM offers reliable, flicker-free dimming for a wide range of lamp types, making it a versatile choice for modern lighting control in residential and commercial installations.
