Kaiser Elektro izolačný predlžovací krúžok 1155-02, 12 mm, sivý

The Kaiser Elektro Iso-Verlängerungsring 1155-02 is a high-quality insulating extension ring designed for flush-mounted and cavity wall electrical installation boxes. It increases the installation depth by 12 mm, providing additional space for electrical devices such as switches, sockets, and dimmers. Made from halogen-free plastic, this extension ring ensures safety and durability. Its grey colour and standard dimensions (outer diameter 74 mm, inner diameter 60 mm) make it compatible with most standard device and junction boxes (Ø60 mm device opening). The ring is screw-mounted and complies with VDE standards, guaranteeing reliable performance in electrical installations.

Advantages

This extension ring offers several benefits: it is halogen-free, reducing toxic fumes in case of fire; it is made of insulating plastic, preventing electrical conductivity; and its 12 mm depth allows for easy accommodation of deeper devices without compromising safety. The ring is easy to install with screws and fits both flush-mounted and cavity wall boxes, making it versatile for various applications.

Suitable for

• Increasing installation depth in flush-mounted (UP) and cavity wall (Hohlwand) electrical boxes
• Accommodating switches, sockets, dimmers, and other electrical devices that require extra depth
• Use in residential, commercial, and industrial electrical installations

Key specifications

• Product Type: Extension Ring
• Application: Electrical Installation Boxes
• Mounting Type: Flush-mounted and Cavity Wall
• Extension Depth: 12 mm
• Material: Plastic
• Halogen-free: Yes
• Colour: Grey
• Outer Diameter: 74 mm
• Inner Diameter: 60 mm
• Insulation Property: Insulating
• Compatibility: Standard device and junction boxes (e.g., Ø60mm device opening)
• Standards Compliance: VDE
• Installation Method: Screw-on
• Series: Kaiser 1155

Recommendations

For optimal safety and performance, use this extension ring with compatible Kaiser Elektro junction boxes and devices. Always follow local electrical codes and regulations during installation.
