Lindy 10m Hybridný optický kábel DP 2.0 UHBR10, 10 m, DisplayPort, DisplayPort, samec, samec, 7680 x 4320 pixelov

The Lindy 10m Fibre Optic Hybrid DP 2.0 UHBR10 Cable is a hybrid copper and fibre optic cable designed for long-distance DisplayPort connections. It supports the DisplayPort 2.0 standard with UHBR10 and a bandwidth of 40Gbps.

Key features

• Hybrid copper and fibre optic construction
• Supports DisplayPort 2.0 with UHBR10
• 40Gbps bandwidth (4 lanes, 10 Gbps per channel)
• Flexible and robust cable structure
• Gold-plated pins

Specifications

• Brand: Lindy
• MPN: 38520
• Product colour: Black
• Connector 1: DisplayPort (Male)
• Connector 2: DisplayPort (Male)
• Cable length: 10 m
• DisplayPort version: 2.0
• Supported bandwidth: 40Gbit/s
• Max. resolution: 7680x4320@60Hz 4:2:0 10Bit, 3840x2160@144Hz 4:4:4 10Bit
• Housing material: PVC
• Pin construction: Gold
• Pin coating: Gold
• Type: Round
• Jacket diameter: 4.0mm
• Jacket material: PVC
• Conductor material: Fibre optic and copper
• Conductor size: 24AWG
• Min. bending radius: 50mm
• Operating temperature: -10°C - 60°C
• Storage temperature: -20°C - 70°C
