LogiLink FA01SC4 SC/SC duplex multimode optická spojka, béžová

Fiber optic SC/SC duplex coupler for multimode networks, providing a precise and stable connection between two SC connectors in patch panels, ODFs, and FTTH applications. The phosphor bronze sleeve ensures low insertion loss and high return loss for reliable signal transmission.

Advantages

Precision alignment with phosphor bronze sleeve, durable plastic housing, and panel-mount flange for secure installation. Supports over 500 mating cycles, ensuring long-term performance in demanding environments.

Suitable for

• Fiber optic patch panels and distribution frames
• FTTH (Fiber to the Home) installations
• Multimode fiber network interconnections

Key specifications

• Connector type: SC to SC
• Configuration: Duplex
• Fiber type: Multimode
• Insertion loss: ≤ 0.3 dB
• Return loss: ≥ 35 dB
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +85°C
• Durability: > 500 mating cycles
• Mounting: Panel mount with flange
• Compliance: RoHS, REACH

Recommendations

Ideal for technicians and network installers who need a reliable, low-loss SC duplex adapter for multimode fiber systems. Pair with LogiLink patch cables for a complete solution.
