Märklin 46719 H0 digitálny DB železničný žeriav

This H0 scale model replicates the Krupp-Ardelt 160 t railway crane as operated by Deutsche Bahn AG in Era V. Unlike static crane models, the 46719 features full digital control of slewing, boom, and hook movements, plus working lights and sound. The metal chassis and extendable outriggers provide realistic operation on any H0 layout with a minimum radius of 360 mm.

Highlights

• Built-in mfx+/DCC digital decoder for multi-protocol operation
• Motorized crane slewing, boom raising/lowering, and hook raising/lowering
• Working lights: work lights, warning lights (flashing), and cab lighting
• Multiple operating sounds including crane motor, horn, and compressor
• Manually extendable support outriggers and counterweight for stable lifting
• Smoke generator contact for optional smoke effect

In daily use

The crane's NEM shaft with close coupling mechanism allows it to be coupled to other rolling stock. With up to 16 controllable functions depending on the control unit, you can operate the crane realistically on both Märklin AC and DCC digital layouts. The metal chassis ensures durability and smooth running.

Full specifications

• Scale: H0 (1:87)
• Era: V (1990-2007)
• Prototype: Krupp-Ardelt 160 t Railway Crane
• Railway Company: Deutsche Bahn AG (DB AG)
• Control System: Märklin Digital (mfx+, DCC, Analog compatible)
• Decoder Type: Built-in mfx+/DCC digital decoder
• Minimum Operating Radius: 360 mm
• Length Over Buffers (LüP): 237 mm
• Chassis Material: Metal
• Superstructure Material: High-quality plastic
• Power System: AC (Märklin) / DC (DCC)
• Power Supply: 16-24V AC/DC

Final note

A digitally controlled crane that brings heavy lifting operations to your H0 layout with authentic motion, light, and sound.
